Wall mounted cleaning nozzles
使用阿法拉伐罐壁式清洗噴頭可 100% 清潔儲罐陰影區域。 此清洗噴嘴可安裝在儲罐的壁口或底部，通過與頂裝式儲罐清洗機配合使用，可清潔底部的攪拌器葉片、線圈和其他難以觸及的區域。 它的可調清洗噴嘴具有經過優化的高沖擊噴霧模式，可消除與儲罐清洗不足相關的風險，確保更高的產品產量、更好的最終產品質量并降低運營成本。
更高效的儲罐清洗可提高工藝效率和安全性，而且還可以提高產品質量和產量
- 100% 的儲罐陰影區域清洗覆蓋率可實現更快的批量和連續工藝轉換，而且更安全且無污染
- 經過優化的高沖擊噴霧模式可消除產品污染風險
- 即使在低壓下也能高效、精確地清洗儲罐，最多可減少 80% 的能源、水和清潔介質的使用
- 易于安裝、操作和清潔
- 更快獲得投資回報
阿法拉伐罐壁式清洗噴嘴
通過將阿法拉伐罐壁式清洗噴嘴與任何頂裝式儲罐清洗機配合使用，可消除儲罐中的風險和污染，從而提高生產力、安全性和產量。 選擇標準的介質驅動型號或 UltraPure 型號以及最適合您工藝的噴霧模式（無論儲罐尺寸、設計或清潔任務如何）。 選項包括用于過程監控和反饋的氣動模型和控制單元。 這種經濟高效的儲罐清洗噴嘴利用加壓清潔介質來專門用于清洗陰影區域。 它非常適用于乳制品、食品、飲料、家庭個人護理、制藥和其他行業，可降低能源、水和清潔介質成本，最大限度地減少對環境的影響并提供較低的總擁有成本。
罐壁式清洗噴嘴的工作原理?
Installed flush with the surface of the tank wall or bottom, a wall mounted tank cleaning nozzle contains a spring-activated piston, which opens and closes the nozzle depending on the pressure of the cleaning media. It is available in two versions: media driven or air-operated. During the Cleaning-in-Place process, the pressure created by the cleaning media activates the media-driven version, while the pneumatic air-operated version has an actuator, which automatically opens the nozzle by means of controlled air pressure. When activated, the wall mounted nozzle sprays a high impact fan of cleaning media directly toward the soiled area. Through controlled and repeated rotation of the equipment with shadow areas, such as agitator blades, the wall mounted tank cleaning nozzle hits the shadow areas, ensuring 100% cleaning coverage and high-precision, high-impact cleaning. Upon completion of the cleaning cycle, the integrated spring mechanism returns the piston to its original position, securely closing and sealing off the wall mounted cleaning nozzle. If purging is required, always operate with actuator.
Safeguard cheese production with 100% cleaning coverage of tank shadow areas
To increase cheese production by expanding its milk reception, a large Scandinavian dairy turned to the Beritech Group, an experienced tank and system builder. The objective was to guarantee complete cleaning coverage for two new 30-metre-high raw milk silos with bottom-mounted agitators.
完整描述
Close at hand catalogue about tank equipment
At your fingertips: Alfa Laval hygienic tank cleaning equipment to ensure fast, effective cleaning cycles that save energy and water. Our ‘Close at hand’ catalogue details everything you need for high cleaning efficiency with static spray balls, rotary spray heads and rotary jet heads. What you get is increased safety, more uptime, and greater productivity.
Services for Hygienic Tank Equipment
Get more out of your hygienic processing lines. Keep your Alfa Laval tank cleaning machines in top operating condition through services that extend the lifetime of your static spray balls, rotary spray heads and rotary jet heads. Let our global service network and local service experts optimize performance and provide you with total peace of mind.
發展你的業務優化你的可持續的流體處理系統
讓您的工藝更高效、更可持續，同時實現監管合規，確保您的業務蓬勃發展。通過阿法拉伐的可持續優化，您可以節省高達80%的能源，以及90%的節水和清潔介質，同時最大限度地減少浪費；對人有益，地球有益，有利于盈利。
讓您的可持續發展戰略成為現實
獲得更多的能源和水的節約，減少您的衛生加工生產線的排放。我們的月刊《近在咫尺》為您帶來阿法拉伐如何支持您提高乳品、食品、飲料、家庭護理和制藥行業的環境績效的故事。對人類和地球有益，也對您的業務有益。
